Lexmark MS310 4514-220 - Controller Board Removal

4 Remove the two screws (A) securing the fan mount to the printer.
A
5 Remove the two screws (B) securing the fan to the fan mount.
B
Controller board removal
1 Remove the right cover. See “Right cover removal” on page 209.
2 Disconnect all cables from the controller board.
4514-2xx
Parts removal
210
