Lexmark MS310 4514-220 - Cartridge Gearbox Removal

d Secure the cable with a cable tie (A).
A
Cartridge gearbox removal
1 Remove the left cover. See “Left cover removal” on page 194.
2 Remove the four screws (A) securing the cartridge gearbox.
A
3 Disconnect the cable from the cartridge gearbox.
4514-2xx
Parts removal
206
