[x]‑page jam, open rear door. [20y.xx]
1 Press the button on the right side of the printer, and then open the front door.
2
1
2 Gently pull down the rear door.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a
hot component, allow the surface to cool before touching it.
3 Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
4514-2xx
Diagnostics and troubleshooting
88
