c Install the right front mount to the printer.
Front access cover removal
1 Remove the right cover. See “Right cover removal” on page 209.
2 Remove the front door. See “Front door removal” on page 231.
3 Remove the nameplate. See “Nameplate removal” on page 223.
4 Remove the MPF assembly. See “MPF assembly removal” on page 226.
5 Remove the bezel. See “Bezel removal” on page 222.
6 Remove the control panel assembly. See “Control panel assembly removal” on page 223.
7 The front access cover remains.
Front door sensor removal
1 Remove the front door. See “Front door removal” on page 231.
2 From under the right front mount, remove the screw (A).
Note: Use a #0 Phillips screwdriver.
4514-2xx
Parts removal
234
