# Light or button Color Description
5 Ready or data light
Green The printer is in Ready state.
6 Sleep button and light
Amber Use this to enable Sleep mode or Hibernate mode.
7 Start button and light
Green Use this to initiate a print job.
8 Stop or cancel button
Red Use this to cancel a print job.
Light sequences and error messages
User attendance messages, paper jam messages, and service errors display a light sequence. If is quickly
pressed twice (the button is pressed and released twice within 0.5 seconds), a secondary pattern may appear
with more detailed information. If
is again quickly pressed twice, the primary pattern usually returns. Not
all primary light sequences have secondary patterns. In which case, quickly pressing
twice does not change
the pattern.
All service errors are indicated by all lights flashing as the primary light sequence. The secondary sequence
indicates an area or function which has the error. Additional tertiary sequences are used to indicate specific
errors.
Light sequences
Legend
Symbol Meaning
•Light on
Light o
* Light blinking
x Light blinking slowly
Status screens
Each screen of information provides various status information to the user. Each status screen includes the
capability to display a warning message.
4514-2xx
Diagnostics and troubleshooting
37
