Error code Description Action
202.45 During warm up flush, sheet detected too long
over exit sensor.
Go to
“Sensor (fuser exit) jam service check” on
page 100.
Sensor (fuser exit) jam service check
Action Yes No
Step 1
Check the input sensor area for jammed media fragments.
Is the paper path free of partially fed or jammed media?
Go to step 2. Clear the paper path
of any media
fragments.
Step 2
Check the fuser exit sensor cable JEXIT1 for proper connection to
the controller board.
Is it properly connected?
Go to step 3. Reseat the cable.
Step 3
Check the fuser exit sensor for damage.
Is it free of damage?
Go to step 4. Replace the fuser.
See
“Fuser
removal” on
page 262.
Step 4
Check the fuser gears and rollers for damage.
Are they free of damage?
Go to step 5. Replace the fuser.
See
“Fuser
removal” on
page 262.
Step 5
Does the error remain?
Contact the next
level of support.
The problem is
solved.
23y paper jams
23y paper jam messages
Error code Description Action
230.01 Sheet covering internal duplex sensor during
warm up.
Go to
“Duplex service check” on page 101.
230.02 Paper jam around internal duplex. Go to
“Duplex service check” on page 101.
230.03 Internal duplex sensor never made by leading
edge of page.
Go to
“Duplex service check” on page 101.
230.04 Page in duplexer ahead of current reversing page
never staged.
Go to
“Duplex service check” on page 101.
230.05 Internal duplex sensor never broke on the trailing
edge of the sheet.
Go to
“Duplex service check” on page 101.
230.07 Internal duplex sensor never broke from sheet
ahead of page.
Go to
“Duplex service check” on page 101.
4514-2xx
Diagnostics and troubleshooting
100
