Service menus
Navigating through the Service menus
Menus are represented by the light sequences. Menu options and their values are
represented by the
light sequences.
To navigate through the Service menus:
1 Press to advance to the desired menu.
2 Press to advance to the desired menu option value.
3 Press and hold until all of the lights cycle to perform the function or save the menu option value.
4 Press and hold to return to the home menu.
5 POR the printer to exit the Service menus.
Diagnostics menu
Entering the Diagnostics menu
1 Turn
o
the printer.
2 Open the front access cover.
3 Press and hold .
4 Turn on the printer.
5 Release the button after 10 seconds.
Print Diagnostics Menu Instruction Sheet
This prints a page that contains:
• Instructions on how to navigate through the Diagnostics menu settings
• The order of the Diagnostics menu settings, the LED pattern that represents each setting, the current value
of each setting, and each setting’s possible values
Print Quality Pages
This enables the user to view the values of the printer settings and to test its ability to generate acceptable
printed output.
4514-2xx
Service menus
161
