Lexmark MS310 4514-220 - Duplex Sensor and Input Sensor Removal

6 Remove the four screws (A) securing the duplex.
A
Note: The duplex link (B) is part of the FRU.
B
Duplex sensor and input sensor removal
1 Remove the left cover. See “Left cover removal” on page 194.
2 Remove the right cover. See “Right cover removal” on page 209.
3 Remove the rear door and cover. See “Rear door and cover removal” on page 256.
4514-2xx
Parts removal
242
