Lexmark MS310 4514-220 - MPF Gearbox Removal

MPF gearbox removal
1 Remove the left cover. See “Left cover removal” on page 194.
2 Remove the main drive gearbox. See “Main drive gearbox removal” on page 195.
3 Remove the front door. See “Front door removal” on page 231.
4 Disconnect the spring (A) from the printer.
A
4514-2xx
Parts removal
200
