Top side removals
Top cover removal
1 Remove the right cover. See “Right cover removal” on page 209.
2 Remove the left cover. See “Left cover removal” on page 194.
3 Remove the rear door and cover. See “Rear door and cover removal” on page 256.
4 Open the front door.
5 Remove the two screws (A) in front.
A
6 Remove the two screws (B) at the rear.
B
7 Lift the top cover to remove.
4514-2xx
Parts removal
263
