10 Remove the screw (B).
B
A
11 Pull out the ACM clutch, and cut the cable to detach the ACM clutch.
12 Remove the other half of the cable from the printer.
Installation notes:
a Pull out the shaft.
b Reinstall the ACM clutch.
c Route the cable using the new path.
