Lexmark MS310 4514-220 - Page 213

B
5 From behind the right cartridge guide, release the 4 latches (C) to detach the toner cartridge smart chip
contact.
Note: Pay attention to the original position of the spring and the actuators.
C
4514-2xx
Parts removal
213
