Lexmark MS310 4514-220 - Page 224

4 Remove the screw (A) securing the ground connector to the controller board.
A
5 Disconnect the cable JOPP1 or JOPP2 from the controller board.
6 Remove the screw (B) from the right front mount, and route the cable through the slot.
B
4514-2xx
Parts removal
224
