June 18, 2015
• Updated “Frame” on page 286 to change the part numbers for the pick tires (from 41X0547 to 41X0918)
and ACM assembly (40X8260 to 41X0919).
May 21, 2015
• Updated the wiring diagram.
April 23, 2015
• Updated the 97y error code table and created “Network port error service check” on page 146 for the
97y error codes.
• Updated the 98y error code table and created “Option communication error service check” on page 147
for the 98y error codes.
• Updated the 99y error code table and created “Option communication error service check” on page 147
for the 99y error codes.
March 19, 2015
• 40X8303 FRU was renamed to ‘250-sheet tray insert (standard tray only)’
• 40X8305 FRU was renamed to ‘250-sheet tray insert (option tray only)’
• 40X8260 FRU was renamed to ‘ACM assembly (standard tray only)’
• 40X8262 FRU was renamed to ‘ACM assembly (option tray only)’
December 4, 2014
• Updated the LSU removal procedure.
October 17, 2014
• Updated the ACM clutch removal procedure.
• Frame parts catalog assembly table—Removed the insulated displacement connectors (IDC) from 40X8265.
October 9, 2014
• Updated the illustration of Electronics 2 parts catalog assembly to show the correct toner cartridge smart
chip contact.
September 8, 2014
• Changed part number 40X8296 to 41X0547.
August 15, 2014
Updated the following service checks:
• Toner cartridge smart chip contact service check
• Cartridge gearbox service check
• LSU service check
• Tray 1 jam service check
4514-2xx
Change history
23
