Lexmark MS310 4514-220 - Page 238

9 While pressing down the MPF sensor flag and separator pad, move the restraint roller (G) to the right.
G F
10 Remove the E‑clip (H), and then move the shaft (I) to the right.
I
H
11 Remove the separator pad and the spring underneath.
4514-2xx
Parts removal
238
