Lexmark MS310 4514-220 - Page 265

9 Remove the three screws (B) securing the LSU.
A
B
Installation note: Mechanical and electronic LSU adjustments are required to complete the installation of the
LSU. See
“Printhead assembly mechanical adjustment” on page 192.
4514-2xx
Parts removal
265
