Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8520 1 1Dust cover (250‑sheet
tray)
“Dust cover removal” on page 256
2 40X8054 1 1 Rear door and cover
“Rear door and cover removal” on
page 256
340X8052 1 1Right cover
“Right cover removal” on page 209
4 40X8303 1 1 250-sheet tray insert
(standard tray only)
N/A
5 40X8056 1 1 Front access cover
“Front access cover removal” on
page 234
640X9148 1 1Cartridge plunger
“Cartridge plunger removal” on
page 219
7 40X8302 1 1 MPF assembly (50
sheets)
“MPF assembly removal” on
page 226
8 41X0994 1 1 MPF tray links
“MPF assembly removal” on
page 226
940X8051 1 1Nameplate
“Nameplate removal” on page 223
10 40X8058 1 1 Control panel cover and
buttons
Note: Does not include
the UICC.
“Control panel assembly removal” on
page 223
“UICC removal” on page 225
11 40X8062 1 1 Bezel (MS310d)
“Bezel removal” on page 222
11 40X8063 1 1 Bezel (MS310dn)
“Bezel removal” on page 222
12 40X8053 1 1 Left cover
“Left cover removal” on page 194
13 40X8055 1 1 Top cover
“Top cover removal” on page 263
14 41X2300 1 1 Access cover link N/A
NS 40X8273 4 40 Rubber foot N/A
4514-2xx
Parts catalog
280
