Lexmark MS310 4514-220 - Page 282

Assembly 2: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8082 1 1 Laser scanning unit
“Laser scanning unit (LSU) removal” on
page 264
240X8343 1 1Fuser, 100 V
“Fuser removal” on page 262
2 40X8023 1 1 Fuser, 110 V
“Fuser removal” on page 262
240X8024 1 1Fuser, 220 V
“Fuser removal” on page 262
3 40X8050 1 1 Narrow media/bin full
sensor
“Narrow media/bin full sensor
removal” on page 257
4 40X8276 1 1 Cooling fan
“Cooling fan removal” on page 209
5 40X8025 1 1 Controller board
(MS310d)
“Controller board removal” on
page 210
5 40X8026 1 1 Controller board
(MS310dn)
“Controller board removal” on
page 210
6 40X8280 1 1 Front input guide
“Front input guide removal” on
page 235
7 40X8300 1 1 MPF solenoid
“MPF solenoid removal” on page 197
8 40X8301 1 1 Reverse solenoid
“Reverse solenoid removal” on
page 203
940X8290 1 1Control panel
assembly
“Control panel assembly removal” on
page 223
NS 41X0913 1 1 Video cable ‑‑
4514-2xx
Parts catalog
282
