Lexmark MS310 4514-220 - Page 287

Assembly 4: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8393 1 1Transfer roll
“Transfer roll removal” on
page 218
2 40X8298 1 1 Redrive assembly
“Redrive assembly removal” on
page 259
3 40X8850 1 1 Redrive shaft
“Redrive shaft removal” on
page 260
4 40X8299 1 1 Front mounts
“Left front mount removal” on
page 214
“Right front mount removal” on
page 216
5 40X8275 1 1 Duplex assembly
“Duplex removal” on page 241
6 41X0918 2 2 Pick tires N/A
7 41X0919 1 1 ACM assembly (standard tray
only)
“ACM assembly removal” on
page 251
8 40X8295 1 1 MPF pick roller and separator
pad
“MPF pick roller removal” on
page 229
“Separator pad removal” on
page 237
9 40X8279 1 1 Jam access cover
“Jam access cover removal” on
page 230
10 40X8278 1 1 MPF gearbox
“MPF gearbox removal” on
page 200
11 40X8277 1 1 Duplex gear assembly
“Duplex gear assembly removal”
on page 207
12 40X8265 1 1 ACM clutch
“ACM clutch removal” on
page 204
13 40X8083 1 1 Cartridge gearbox
“Cartridge gearbox removal” on
page 206
14 40X8085 1 1 Main drive gearbox
“Main drive gearbox removal” on
page 195
NS 40X8394 1 1 Screw kit, contains:
• MT3x0.5+8PF‑NI—10
pieces
• MT3x0.5+6PF‑NI—10
pieces
• TP2NC‑3+6PF‑NI—10
pieces
N/A
4514-2xx
Parts catalog
287
