7 Remove the two screws (C) securing the control panel assembly.

8 Route all cables off the printer to completely remove the control panel assembly.

Control panel assembly removal (MS610de)

1 Remove the right cover. See “Right cover removal” on page 178.

2 Remove the nameplate. See “Nameplate removals” on page 199.

3 Remove the bezel. See “Bezel removals” on page 197.

4514-630, -635, -636

Repair information

203
