Lightware UMX-TPS-TX100 Series

11. Appendix UMX-TPS-TX100 series – User's Manual 114

HDMI port connector type .................19-pole HDMI Type A receptacle
Standard ..................................................................... DVI 1.0, HDMI 1.4
Color depth ....................
Color space ............................................ RGB, YCbCr 4:4:4, YcbCr 4:2:2
Max. video resolutions .............................. 1920x1080@120 Hz, 24 bit
.......................................................................1600x1200@60 Hz, 36 bit
.......................................................................3840x2160@30 Hz, 24 bit
Audio formats ........................................8 channel PCM, Dolby TrueHD
....................................................................... DTS-HD Master Audio 7.1
Reclocking .................................................... Pixel Accurate Reclocking
3D support ..........................................................................................Yes
HDCP compliant..........................................................................Yes, 1.1
DisplayPort Input
DisplayPort connector type .......................20-pole, DP 1.1a receptacle
Color depth ....................
Color space ............................................ RGB, YcbCr 4:4:4, YCbCr 4:2:2
Max. video resolutions ..........................................1920x1080@120 Hz
..................................................................................2560x1600@60 Hz
..................................................................................4096x2400@30 Hz
3D support ..........................................................................................Yes
HDCP compliant..........................................................................Yes, 1.3
DVI-I Input with DVI-D support
Connector type ................................................................... 29-pole, DVI-I
Standard ..................................................................... DVI 1.0, HDMI 1.4
Color depth ....................
Color space ............................................ RGB, YCbCr 4:4:4, YcbCr 4:2:2
Max. video resolutions .............................. 1920x1080@120 Hz, 24 bit
.......................................................................1600x1200@60 Hz, 36 bit
.......................................................................3840x2160@30 Hz, 24 bit
Audio formats ........................................8 channel PCM, Dolby TrueHD
....................................................................... DTS-HD Master Audio 7.1
Reclocking .................................................... Pixel Accurate Reclocking
3D support ..........................................................................................Yes
HDCP compliant..........................................................................Yes, 1.1
DVI-I Input with DVI-A support
Connector type ................................................................... 29-pole, DVI-I
Supported video signal ........................... Analog RGB and YPbPr video
Color depth ...................................................... 
Max. data rate ..................Up to 170 MHz video and graphics digitizer
Max. resolution ..............................................Up to 1600x1200@60 Hz
TPS Output Port
TPS port connector type............................................... 
Compliance ...........................................................................HDBaseT
TM
Transferred signals ................ Video, Audio, RS-232, Infrared, Ethernet
Max. video resolutions .............................. 1920x1080@120 Hz, 24 bit
.......................................................................1600x1200@60 Hz, 36 bit
.......................................................................3840x2160@30 Hz, 24 bit
Audio Ports
Embedded Audio Signal
Supported on .........................................DisplayPort, DVI-D, HDMI ports
Supported audio formats ....................................Up to 8 channel PCM,
...........................................................................................Dolby TrueHD
.........................................................DTS HD Master Audio 7.1 formats

Connector type ..................................... 
Sampling frequency ..................................................................... 48 kHz
Volume............................................................................... -95.62 – 0 dB
Maximum input level ............................... +0 dBu, 0.77 Vrms, 2.19 Vpp

Connector type .............................................. 5-pole Phoenix connector
Signal transmission ........................... Balanced and unbalanced audio
Sampling frequency ..................................................................... 48 kHz
Volume............................................................................... -95.62 – 0 dB
Maximum input level ............................... +4 dBu, 1.23 Vrms, 3.47 Vpp
Control Ports
RS-232
Connector type .............................................. 3-pole Phoenix connector
Available Baud rates ..........................between 4800 and 115200 baud
Available Data bits ......................................................................... 8 or 9
Available Parity.......................................................... 
Available Stop bits ...................................................................
Infrared
Number of IR ports ....................................................... 2 (1x RX, 1x TX)
Connector type 
Ethernet
Connector type ..................................................................
Ethernet data rate .............. 
Power over Ethernet (PoE) ..............................................Not supported
GPIO
Connector type .............................................. 8-pole Phoenix connector
 ................................................................7
Port direction................................................................... Input or output
Input voltage: Low level .............................................................0 - 0,8 V
Input voltage: High level ............................................................... 2 - 5 V
Output voltage: Low level ...........................................................0 - 0,5 V
Output voltage: High level ......................................................... 4.5 - 5 V
Max. current: Low level .................................................................30 mA
Max. current: High level ................................................................ 18 mA
Total available current ................................................................180 mA
EDID Management
EDID emulation ....... Yes, both on the analog and on the digital inputs
EDID memory .................. 120 factory presets, 15 user-programmable




