Lightware UMX-TPS-TX100 Series

 UMX-TPS-TX100 series – User's Manual 95
Sending CEC Commands
ATTENTION! CEC command sending feature is available only in UMX-TPS-TX140-Plus and



is output, it is always 40 (from Playback device 1. to TV). Broadcast addressing is also possible (in this
case it is 0F or 4F).
Parameters
Parameter Description
<port> HDMI input (I2) and TPS output (O1) port.
Sending an OSD String
Sending the OSD string consists of two steps. First, set the CEC.OsdString property with the desired text, after
that, call the CEC.send(set_osd) method.

Command and Response
Î <port>.OsdString=<text>
Í <port>.OsdString=<text>
Parameters
<text> Letters (A-Z) and (a-z), hyphen (-), underscore (_), numbers (0-9), and dot (.). Max length: 14
characters.
Example
Î 
Í 

Command and Response
Î <port>:send(set_osd)
Í 
Example
Î 
Í 
Sending a CEC Command in Text Format
Command and Response
Î <port>:send(<command>)
Í <port>:send
Parameters
The followings are accepted as <command>:
image_view_on standby ok back up
down left right root_menu setup_menu
contents_menu favorite_menu media_top_menu media_context_menu number_0
number_1 number_2 number_3 number_4 number_5
number_6 number_7 number_8 number_9 dot
enter clear channel_up channel_down sound_select
input_select display_info power_legacy page_up page_down
volume_up volume_down mute_toggle mute unmute
play stop pause record rewind
fast_forward eject skip_forward skip_backward 3d_mode
stop_record pause_record play_forward play_reverse select_next_media
select_media_1 select_media_2 select_media_3 select_media_4 select_media_5
power_toggle power_on power_off stop_function f1
f2 f3 f4
Example
Î 
Í 

Î <port>:sendHex(<hex_code>)
Í <port>:sendHex
Parameters
<hex_code> Accepted command is max. 30 character long (15 byte) in hexadecimal format.
Example
Î 
Í 




