Lightware UMX-TPS-TX100 Series

 UMX-TPS-TX100 series – User's Manual 65
View Firmware Version of the CPU
Description
Format Example
Command {f}

 {f}

Legend
Connection Test
Description: Simple test to see if the connection is established successfully.
Format Example
Command {PING}
Response (PONG!)CrLf
 {ping}
 (PONG!)
View Serial Number
Description: The device responds its 8-digit serial number.
Format Example
Command {s}
Response (SN:<SERIAL_N>)CrLf
 {s}
 (SN:5A003192)
Compile Time
Description
Format Example
Command {CT}
Response (Complied: <DATE&TIME>)CrLf
 {ct}
 (Compiled: May 11 2019 11:10:09)
View Installed Board
Description: Shows the hardware name and revision of the installed card.
Format Example
Command {is}
Response (SL#●0●<MB_DESC>)CrLf
(SL●END)CrLf
 {is}
 (SL# 0 UMX-TPS-TX140 V11_2A)
 (SL END)
Explanation: The device reports its motherboard (slot 0).
View Firmware for All Controllers
Description
Format Example
Command {FC}
Response (CF●<DESC>)CrLf
(CF●<DESC>)CrLf
…
(CF END)CrLf
 {fc}
 (CF UMX-TPS-TX140 1.3.2b1 r43)
 (SL END)
Explanation: The device has one control panel.
Restart the Device
Description: The device can be restarted without unplugging power.
Format Example
Command {RST}
Response
 {rst}
Explanation: The device reboots; no response is sent in this case.

Description: Internal voltages and measured temperature values are shown.
Format Example
Command {ST}
Response (ST●<DESC>)CrLf
 {st}
 (ST CPU 11.61V 5.03V 1.84V 1.28V 0.99V
42.24C 42.23C)
Restore Factory Default Settings
Description: Settings can be reset to factory default values as follows:
Format Example
Command {FACTORY=ALL}
Response (FACTORY ALL…)CrLf
 {factory=all}
 (FACTORY ALL…)
Explanation: All settings and parameters are reset to factory default, see the table in the Factory Default
Settings section.




