 UMX-TPS-TX100 series – User's Manual 82
TPS Mode Settings
Command and Response
Î <port>.tpsModeSetting=<tps_mode>
Í <port>.tpsModeSetting=<tps_mode>
Parameters
See at previous section.
Example
Î 
Í 
Audio Port Settings
INFO: Audio port numbering can be found in the Port Numbering section.

Command and Response
Î 
Í <in1_state>;<in2_state>;<…>; <in#_state>

the next four characters represent a 2-byte HEX code showing the current state of the input ports.
Example
Î 
Í 
Legend:
Letter (Character 1)
Mute state Lock state
T
Unmuted Unlocked
L
Unmuted Locked
M
Muted Unlocked
U
Muted Locked
T 0 0 0 F
Mute / Lock status
Reserved character, always 0.
Reserved character, always 0.
Reserved character, always 0.
Signal present / Connection status
Letter
Byte 1
Byte 2
Byte 1 Byte 2
Character 2 Character 3 Character 4 Character 5
BIT 7-6 BIT 5-4 BIT 3-2 BIT 1-0 BIT 7-6 BIT 5-4 BIT 3-2 BIT 1-0
Reserved Reserved Reserved Reserved Reserved Reserved
Signal
present
status
Connection
status
0 0
Reserved Reserved Reserved Reserved Reserved Reserved
Unknown
0 1
Reserved
1 0
No signal
Not
connected
1 1
Signal
presents
Connected




