CEC Application Example

to wake up.
Create an event in the event manager:
▪ Set as a condition, that the signal is present on the output (O1),
▪ Set as an action then send a CEC command 'Image view on' O1 output port.
See the details about the Event Manager settings in the Event Manager section.
ATTENTION! The CEC command sending over TPS interface is working only with CEC-transparent
TPS receivers. For the details please download our Using CEC in Lightware Devices document on
 website.
Further Built-in Features

The Event Manager feature means that the device can sense changes on its ports and is able to react


Event Manager example
See more information about the settings in the Event Manager section.
UMX-TPS-TX140-Plus HDTV
HDMI OUT
Laptop
HDMI IN
VIDEO AUDIO
DVI-A Video
Autoselect
HDCP
Audio2
DVI-D
DP
DVI-D
DP
SHOW
ME
AUDIO
SELECTINPUT STATUS
VIDEO
SELECT
HDMI HDMI
VGA
Audio1
RESET
AUDIO1 IN HDMI IN DP IN VGA IN
TPS receiver
TPS OUT
Connect Turn on
Video signal is detected on HDMI port I2
CONDITION
Turn on the projector connected to the local serial port
ACTION
UMX-TPS-TX100 series transmitterBlu-ray player
Projector
VIDEO AUDIO
DVI-A Video
Autoselect
HDCP
Audio2
DVI-D
DP
DVI-D
DP
SHOW
ME
AUDIO
SELECTINPUT STATUS
VIDEO
SELECT
HDMI HDMI
VGA
Audio1
RESET
AUDIO1 IN HDMI IN DP IN VGA IN

             
             
settings. If the devices are installed in the same type of system multiple times then it is enough to set up only

See more information about the settings in the  section.
Remote Firmware Upgrade of Connected Lightware Devices

software. UMX-TPS-TX100 series transmitters and wallplates contain a feature which allows having a faster


connected devices and can upgrade them.
The upgrade process is almost the same as in the case of the usual upgrade process. See the details of the
process in the Remote Firmware Upgrade of Connected Lightware Devices section.
