11. Appendix UMX-TPS-TX100 series – User's Manual 120
UMX-TPS-TX140 / UMX-TPS-TX140-Plus
Audio/Video Ports
Port name
Video port
Emulated
EDID
memory
Audio port
Till fw
v1.0.3
From fw
v1.1.0
Till fw
v1.0.3
From fw
v1.1.0
VGA in I1 P1 I1 E1 - - -
HDMI in I2 P2 I2 E2 I2 P2 I2
DP in I3 P3 I3 E3 I3 P3 I3
DVI-D in I4 P4 I4 E4 I4 P4 I4
DVI-A in I5 P5 I5 E5 - - -
Test pattern I6 P6 I6 - - - -
Audio1 in - - - - I1 P1 I1
Audio2 in - - - - I5 P5 I5
TPS out O1 P7 O1 - O1 P6 O1
IR and RS-232 Ports
Port name Port name
Local IR input S1 Local serial port P1
Local IR output D1 TPS serial link P2
TPS IR input S2
TPS IR output D2
FP-UMX-TPS-TX120
Audio/Video Ports
Port name
Video port
Video port
Emulated
EDID
memory
Audio port
Audio port
VGA in 1 I1 E1 - -
HDMI in 2 I2 E2 2 I2
Test pattern 3 I3 - - -
Audio in - - - 1 I1
TPS out 1 O1 - 1 O1
RS-232 and IR Ports
Port name Port name
Local serial port P1 Local IR input S1
TPS serial link P2 TPS IR input S2
TPS IR output D1
FP-UMX-TPS-TX130
Audio/Video Ports
Port name
Video port
Video port
Emulated
EDID
memory
Audio port
Audio port
VGA in 1 I1 E1 - -
DP in 2 I2 2 I2
HDMI in 3 I3 E2 3 I3
Test pattern 4 I4 - - -
Audio in - - - 1 I1
TPS out 1 O1 - 1 O1
RS-232 and IR Ports
Port name Port name
Local serial port P1 Local IR input S1
TPS serial link P2 TPS IR input S2
TPS IR output D1
Maximum Extension Distances
Resolution
Pixel clock
rate
CAT5e AWG24 CAT7 AWG26** CAT7 AWG23
1024x768@60Hz 65 MHz
1280x720p@60Hz 73.8 MHz
148.5 MHz
1920x1200@60Hz 152.9 MHz
1600x1200@60Hz 162 MHz
223.6 MHz
3840x2160@30Hz UHD 297 MHz
4096x2160@30Hz 4K 297 MHz
