Lightware UMX-TPS-TX100 Series - LW2 Commands - Quick Summary

 UMX-TPS-TX100 series – User's Manual 70

General LW2 Commands
Operation
See in
section
Command
View Product Type 6.2.1 {I}
 6.2.2 {P_?}
View Firmware Version of the CPU 6.2.3 {F}
Connection Test 6.2.4 {PING}
View Serial Number 6.2.5 {S}
Compile Time 6.2.6 {CT}
View Installed Board 6.2.7 {IS}
View Firmware for All Controllers 6.2.8 {FC}
Restart the Device 6.2.9 {RST}
Change the Video Input Priorities 6.2.10 {ST}
Restore Factory Default Settings 6.2.11 {FACTORY=ALL}
AV Port Settings
Operation
See in
section
Command
Switch an Input to the Output 6.3.1 {<in>@<out>●<layer>}
Mute Output 6.3.2 {#<out>●<layer>}
Unmute Output 6.3.3 {+<out>●<layer>}
Lock Output 6.3.4 {#><out>●<layer>}
Unlock Output 6.3.5 {+<out>●<layer>}
View Connection State on the Output 6.3.6 {VC●<layer>}
View Crosspoint Size 6.3.7 {GETSIZE●<layer>}
Change Video Autoselect Mode 6.3.8 {AS_V<out>=<state>;<mode>;<no_signal>}
Change Audio Autoselect Mode 6.3.9 {AS_A<out>=<state>;<mode>;<no_signal>}
Change the Video Input Priorities 6.3.10 {PRIO_V<out>=<in
1
_prio>;…;<in
n
_prio>}
Change Audio Input Priority 6.3.11 {PRIO_A<out>=<in
1
_prio>;…;<in
n
_prio>}

Operation
See in
section
Command
 6.4.1 {IP_STAT=?}
Set the IP Address 6.4.2 {IP_ADDRESS=<type>;IP_ADDRESS}
Set the Subnet Mask 6.4.3 {IP_NETMASK=<subnet_mask>}
Set the Gateway Address 6.4.4 
Apply Network Settings 6.4.5 {IP_APPLY}

Operation
See in
section
Command
Set Level and Direction for Each Pins 6.5.1 {GPIO<pin_nr>=<dir>;<level>}




