1. Introduction UMX-TPS-TX100 series – User's Manual 9
Features
High bandwidth allows extension of resolutions up to 4K
and even 3D sources and displays are supported.
Signal Transmission up to 170 m
Video and audio signal transmission (HDMI, Ethernet,
RS-232, and Infra-Red over a single CAT5e…CAT7e cable.
Analog Audio and Video A/D Conversion
Analog audio and video signals are converted to digital
before being sent to the output.
Deep Color Support and Conversion
It is possible to transmit the highest quality 36-bit video
streams for perfect color reproduction.
Pixel Accurate Reclocking
Each output has a clean, jitter free signal, eliminating
signal instability and distortion caused by long cables or
on the digital video inputs can be disabled when non-
protected content is extended.
Built-in Event Manager
The Event Manager tool takes care of all the necessary
Hence, in a less complex environment, there is no need
to invest in additional control solutions, which makes the
receiver the best choice for numerous applications.
Autoselect Function for Video Inputs
The Autoselect feature can sense the port status on the
video input ports and select automatically one of them.
Priority number can be set for each input port and the
feature allows to set various modes for the automatic
input selection (First detect, Last detect, Priority mode).
Breakaway Audio/Video Switching
audio and video separately by de-embedding and
audio can be de-embedded from the incoming HDMI
stream, then at output a different audio can be embedded
into the video signal from a different source, or audio can
be routed to a separate output port.
Remote Power
The transmitters are PoE-compatible and can be powered
locally by the supplied power adaptor, or remotely via
the TPS connection (through the CATx cable) with a
compatible power source equipment.
TPS Cable Diagnostic Tool
The TPS Cable Diagnostics Tool within the LDC software
will help you identify potential twisted pair cable issues
in your TPS-capable (HDBaseT compliant) system. It
provides a real-time overview of the estimated cable
lengths and the quality of the link.
IR
Infrared (IR) is a wireless technology used for device
communication over short ranges. IR communication
has major limitations because it requires line-of-sight,
has a short transmission range and is unable to penetrate
walls. Infrared is commonly used for remote control
based applications. Third-party control systems may
send IR control commands to endpoints turning them on
and off or switching their inputs. IR capable extenders
can carry the IR signal via CAT cable to greater distances
along with other data.
RS-232
Bi-directional RS-232 Pass-through
AV systems can also contain serial port controllers and
controlled devices. Serial port pass-through supports
any unit that works with standard RS-232.
GPIO Control Port *
7 GPIO pins operating at TTL digital signal levels and can
* Only for UMX-TPS-TX130, UMX-TPS-TX140, and UMX-TPS-TX140-Plus
models.
CEC
Consumer Electronic Control
Supports transmitting standard CEC commands in order
to remote control the source or sink device.
Infra Message Sending
Infrared (IR) is a wireless technology used for device
communication over short ranges. Third party control
systems may send IR control commands to endpoints
turning them on and off or switching their inputs.
RS-232
0100 1
x
RS-232 Recognizer
Support recognizing incoming RS-232 messages to
integrate with 3rd party devices like VC codec.
