 UMX-TPS-TX100 series – User's Manual 80
Test Pattern Generator Mode
The output port can send a special image towards the sink device for testing purposes. The setting is
available on the input ports with the below-listed parameters.
Command and Response
Î <in>.FreeRunMode=<mode>
Í <in>.FreeRunMode=<mode>
Parameters
 Parameter description Value Parameter value
<mode>
Test pattern generator
mode
0
Always off: the test pattern is not displayed on
the output.
1
Always on: the test pattern is displayed on the
output.
2
Auto: the test pattern is displayed if there is no
signal on the input port.
Example
Î 
Í 
Test Pattern Color
Command and Response
Î <in>.FreeRunColor=<RGB_code>
Í <in>.FreeRunColor=<RGB_code>
Parameters
<RGB_code> RGB color in RR;GG;BB format (separated by semicolons).
Example
Î 
Í 
The test pattern color is on VGA input (I1) is set to green.
Test Pattern Resolution
Command and Response
Î <in>.FreeRunResolution=<resolution>
Í <in>.FreeRunResolution=<resolution>
Parameters
 Parameter description Value Parameter value
<resolution>
Applied resolution of the
test pattern generator
0 640x480p60
1 720x480i60
2 720x480p60
3 720x576i50
4 720x576p50
5 800x600p60
6 1024x768p60
7 1280x720p60
8 1280x1024p60
9 1280x1080i60
10 1920x1080p60
11 1920x1200p60
Example
Î 
Í 




