Lightware UMX-TPS-TX100 Series - HDCP Setting (Output Port); HDMI Mode Settings (Output Port); Color Space Setting (Output Port); Query the Recent TPS Mode

 UMX-TPS-TX100 series – User's Manual 81

               
transmitted to a non-HDCP compliant display. See more information in the HDCP Management section.
Command and Response
Î <out>.HdcpModeSetting=<HDCP_mode>
Í <out>.HdcpModeSetting=<HDCP_mode>
Parameters
 Parameter description Value Parameter value
<HDCP_mode> HDCP mode
0 Auto
1 Always
Example
Î 
Í 

Command and Response
Î <out>.HdmiModeSetting=<mode>
Í <out>.HdmiModeSetting=<mode>
Parameters
 Parameter description Value Parameter value
<mode> HDMI mode
0 Auto
1 DVI
2 HDMI 24 bit
3 HDMI 30 bit
4 HDMI 36 bit
Example
Î 
Í 

Command and Response
Î <out>.ColorSpaceSetting=<colorspace>
Í <out>.ColorSpaceSetting=<colorspace>
Parameters
 Parameter description Value Parameter value
<colorspace> Color space conversion
0 Auto
1 RGB
2 YCbCr 4:4:4
3 YCbCr 4:2:2
Example
Î 
Í 

Command and Response
Î <port>. tpsModeSetting
Í <port>. tpsModeSetting =<mode>
Parameters
 Parameter description Value Parameter value
<mode> TPS mode
A Auto
 HDBaseT
L Long reach
1 LPPF1
2 LPPF2
Example
Î 
Í 
INFO: See more information about TPS modes in the TPS Interface section.




