Lightware UMX-TPS-TX100 Series

11. Appendix UMX-TPS-TX100 series – User's Manual 121
Factory EDID List
Mem. Resolution Type Mem. Resolution Type
F1 640 x 480 @ 60.00 Hz D F34 720 x 576 @ 50.00 Hz H
F2 848 x 480 @ 60.00 Hz D F35 1280 x 720 @ 50.00 Hz H
F3 800 x 600 @ 60.32 Hz D F36 1280 x 720 @ 60.00 Hz H
F4 1024 x 768 @ 60.00 Hz D F37 1920 x 1080i @ 50.04 Hz H
F5 1280 x 768 @ 50.00 Hz D F38 1920 x 1080i @ 50.00 Hz H
F6 1280 x 768 @ 59.94 Hz D F39 1920 x 1080i @ 60.05 Hz H
F7 1280 x 768 @ 75.00 Hz D F40 1920 x 1080i @ 60.05 Hz H
F8 1360 x 768 @ 60.02 Hz D F41 1920 x 1080 @ 24.00 Hz H
F9 1280 x 1024 @ 50.00 Hz D F42 1920 x 1080 @ 25.00 Hz H
F10 1280 x 1024 @ 60.02 Hz D F43 1920 x 1080 @ 30.00 Hz H
F11 1280 x 1024 @ 75.02 Hz D F44 1920 x 1080 @ 50.00 Hz H
F12 1400 x 1050 @ 50.00 Hz D F45 1920 x 1080 @ 60.00 Hz H
F13 1400 x 1050 @ 60.00 Hz D F46 1920 x 1080 @ 60.00 Hz H
F14 1400 x 1050 @ 75.00 Hz D F47  H
F15 1680 x 1050 @ 60.00 Hz D F48  H
F16 1920 x 1080 @ 50.00 Hz D F49  H
F17 1920 x 1080 @ 60.00 Hz D F50 720 x 480 @ 30.03 Hz A
F18 2048 x 1080 @ 50.00 Hz D F51 720 x 576 @ 25.04 Hz A
F19 2048 x 1080 @ 60.00 Hz D F52 640 x 480 @ 60.00 Hz A
F20 1600 x 1200 @ 50.00 Hz D F53 640 x 480 @ 75.00 Hz A
F21 1600 x 1200 @ 60.00 Hz D F54 800 x 600 @ 50.00 Hz A
F22 1920 x 1200 @ 50.00 Hz D F55 800 x 600 @ 60.32 Hz A
F23 1920 x 1200 @ 59.56 Hz D F56 800 x 600 @ 75.00 Hz A
F24 2048 x 1200 @ 59.96 Hz D F57 1024 x 768 @ 49.99 Hz A
F25-F28 Reserved D F58 1024 x 768 @ 60.00 Hz A
F29  D F59 1024 x 768 @ 75.03 Hz A
F30 1440 x 480i @ 60.05 Hz H F60 1280 x 768 @ 50.00 Hz A
F31 1440 x 576i @ 50.08 Hz H F61 1280 x 768 @ 59.94 Hz A
F32 640 x 480 @ 59.95 Hz H F62 1280 x 768 @ 75.00 Hz A
F33 720 x 480 @ 59.94 Hz H F63 1360 x 768 @ 60.02 Hz A
Mem. Resolution Type Mem. Resolution Type
F64 1364 x 768 @ 50.00 Hz A F95 Reserved D
F65 1364 x 768 @ 59.94 Hz A F96 2560 x 1600 @ 59.86 Hz D
F66 1364 x 768 @ 74.99 Hz A F97 3840 x 2400 @ 24.00 Hz D
F67 1280 x 1024 @ 50.00 Hz A F98 1280 x 720 @ 60.00 Hz H3D
F68 1280 x 1024 @ 60.02 Hz A F99 1920 x 1080 @ 60.00 Hz H3D
F69 1366 x 1024 @ 60.00 Hz A F100 1024 x 768 @ 60.00 Hz H
F70 1400 x 1050 @ 50.00 Hz A F101 1280 x 1024 @ 50.00 Hz H
F71 1400 x 1050 @ 60.00 Hz A F102 1280 x 1024 @ 60.02 Hz H
F72 1400 x 1050 @ 75.00 Hz A F103 1280 x 1024 @ 75.02 Hz H
F73 1920 x 540 @ 50.00 Hz A F104 1600 x 1200 @ 50.00 Hz H
F74 1920 x 540 @ 60.00 Hz A F105 1600 x 1200 @ 60.00 Hz H
F75 1920 x 1080 @ 50.00 Hz A F106 1920 x 1200 @ 59.56 Hz H
F76 1920 x 1080 @ 60.00 Hz A F107 2560 x 1440 @ 59.95 Hz H
F77 1600 x 1200 @ 50.00 Hz A F108 2560 x 1600 @ 59.86 Hz H
F78 1600 x 1200 @ 60.00 Hz A F109 3840 x 2400 @ 24.00 Hz H
F79 1920 x 1200 @ 59.96 Hz A F110 3840 x 2160 @ 24.00 Hz H
F80 1920 x 1200 @ 50.00 Hz A F111 3840 x 2160 @ 25.00 Hz H
F81-F88 Reserved A F112 3840 x 2160 @ 30.00 Hz H
F89  A F113-F117 Reserved
F90 1920 x 2160 @ 59.99 Hz D F118  H4K
F91 1024 x 2400 @ 60.01 Hz D F119  H4K
F92-F93 Reserved D F120 3840 x 2160 @ 60.00 Hz H4K
F94 2048 x 1536 @ 60.00 Hz D
Legend
Type Description
D DVI EDID
H HDMI EDID
A Analog EDID
DL Dual-Link DVI EDID
H3D HDMI EDID with 3D support
H4K HDMI EDID with 4K resolution support




