11. Appendix UMX-TPS-TX100 series – User's Manual 122
Release Notes of the Firmware Packages
v1.4.0b8
Release date: 2019-07-23
New feature:
▪ Added support for FP-UMX-TPS-TX120-GES, FP-UMX-TPS-
TX130-GES product variants.
▪ New bootloader is used, which allows the connected TPS-RX95's
to be upgraded remotely.
▪
the recent changes in property and node names may result in
▪
▪ The method of storing device settings in EEPROM is upgraded,
which may result in losing all the settings, logs and user EDID's
after upgrading to 1.1.0. The LDU software contains a plug-in to
▪
can be triggered manually for testing and the user interface
shows if any of the conditions are met.
▪
condition and action, a condition can trigger multiple actions at
the same time, inverse condition can be used.
▪ 3840x2160p60 YUV4:2:0 factory EDID added.
▪ IR command injection is now supported: data received on a
frames are also sent to this TCP connection.
▪
▪ EDID node properties changed: PreferredResolution,
MonitorName and AudioInfo properties are added
▪ The device is able to identify IR commands on either the local
or link IR input port. This feature can be connected to Event
Manager, which means, that the device can be programmed to
▪ TCP and UDP messages can be sent by the device to control
projectors and any other devices. This feature can also be used
with Event Manager.
▪ Audio and video port names are changed: 'I' is used for inputs
and 'O' is used for outputs, instead of 'P'.
▪ New EDID driver is used, the content of some factory EDID's are
changed according to EDID 1.3 and 1.4 standard.
▪
▪ Firmware platform library updated
▪ Sending IR codes (SendProntoHex e.g. send max. 200 Byte IR
code with Event Actions) for UMX-TPS-TX140-Plus only!
▪ Added 'Disable default button function' option to support button
customization in Event Manager
▪
mode
▪ CEC - sendCEC command (e.g. turn on the TV with Event Actions)
▪
▪ Added 'Dark mode' function to turn off front panel LEDs
▪
▪ RS232 Minimal Recognizer for Cisco compatibility (Cisco Login)
▪ Improved GPIO detection
▪ Use LDU2 v1.2.5 or later for the upgrade!
▪ Added 'User replaceable miniweb slot' to support built-in control
webpage
▪ Added 'Forced button lock' function to lock buttons via protocol
command
▪ Poe enable state is now reloaded after reboot.
▪ Input video parameter measurement speed improved.
▪ Unsupported dual link DVI EDIDs removed from factory EDID list.
▪
▪ Event manager conditions did not work if DP input properties
were selected.
▪ If the user switched to the currently selected port, the output was
disconnected and connected again unnecessarily, which resulted
in a picture drop. Fixed.
▪ Compatibility issues with Gefen HDMI 1.3 HdBaseT extender
▪ In case of sending DVI signal on the output, the audio output port
does not indicate signal present.
▪ If the output was set to HDCP Always mode, the signal was
sent out unencrypted, if the input port was disconnected and
connected again. This issue only happened, if the input signal
was also unencrypted.
▪ If no sync screen is active, the output resolution is now reported
correctly by the output port.
▪
▪ In case of sending 1920x1200 no sync screen, the device did not
notice the connection state changes on the inputs. Fixed.
v1.3.2b1
Release date: 2019-05-21
▪ Use LDU2 v1.2.5 or later for the upgrade!
v1.3.1b1
Release date: 2019-04-17
▪
v1.3.0b11
Release date: 2019-04-17
New feature:
▪ RS232 Minimal Recognizer for Cisco compatibility (Cisco Login)
for UMX-TPS-TX140-Plus only!
▪ Sending IR codes (SendProntoHex e.g. send max. 200 Byte IR
code with Event Actions) for UMX-TPS-TX140-Plus only!
▪ Use LDU2 v1.2.3 or later for the upgrade!
▪ CEC - sendCEC command (e.g. turn on the TV with Event Actions)
for UMX-TPS-TX140-Plus only!
▪ Fixed Event Manager condition linking
v1.2.1b8
Release date: 2019-01-29
New feature:
▪ Firmware platform library updated
▪
▪ Compatible for LDU2 only!
▪
mode
▪ Added 'Disable default button function' option to support button
customization in Event Manager
