Lightware UMX-TPS-TX100 Series

11. Appendix UMX-TPS-TX100 series – User's Manual 119
Port Numbering
WP-UMX-TPS-TX120-US
Audio/Video Ports
Port name
Video port


Emulated
EDID
memory
Audio port


Till fw
v1.0.3
From fw
v1.1.0
Till fw
v1.0.3
From fw
v1.1.0
VGA in I1 P1 I1 E1 - - -
HDMI in I2 P2 I2 E2 I2 P2 I2
Test pattern I3 P3 I3 - - - -
Audio in - - - - I1 P1 I1
TPS out O1 P4 O1 - O1 P3 O1
RS-232 and IR Ports
Port name  Port name 
Local serial port P1 Local IR input S1
TPS serial link P2 TPS IR input S2
WP-UMX-TPS-TX130-US / WP-UMX-TPS-TX130-US-Plus
Audio/Video Ports
Port name
Video port


Emulated
EDID
memory
Audio port


Till fw
v1.0.3
From fw
v1.1.0
Till fw
v1.0.3
From fw
v1.1.0
VGA in I1 P1 I1 E1 - - -
DP in I2 P2 I2 I2 P2 I2
HDMI in I3 P3 I3 E2 I3 P3 I3
Test pattern I4 P4 I4 - - - -
Audio in - - - - I1 P1 I1
TPS out O1 P5 O1 - O1 P4 O1
RS-232 and IR Ports
Port name  Port name 
Local serial port P1 Local IR input S1
TPS serial link P2 TPS IR input S2
UMX-TPS-TX120
Audio/Video Ports
Port name
Video port


Emulated
EDID
memory
Audio port


Till fw
v1.0.3
From fw
v1.1.0
Till fw
v1.0.3
From fw
v1.1.0
VGA in I1 P1 I1 E1 - - -
HDMI in I2 P2 I2 E2 I2 P2 I2
Test pattern I3 P3 I3 - - - -
Audio in - - - - I1 P1 I1
TPS out O1 P4 O1 - O1 P3 O1
IR and RS-232 Ports
Port name  Port name 
Local IR input S1 Local serial port P1
Local IR output D1 TPS serial link P2
TPS IR input S2
TPS IR output D2
UMX-TPS-TX130
Audio/Video Ports
Port name
Video port


Emulated
EDID
memory
Audio port


Till fw
v1.0.3
From fw
v1.1.0
Till fw
v1.0.3
From fw
v1.1.0
VGA in I1 P1 I1 E1 - - -
HDMI in I2 P2 I2 E2 I2 P2 I2
DVI-D in I3 P3 I3 E3 I3 P3 I3
DVI-A in I4 P4 I4 E4 - - -
Test pattern I5 P5 I5 - - - -
Audio in - - - - I1 P1 I1
TPS out O1 P6 O1 - O1 P4 O1
IR and RS-232 Ports
Port name  Port name 
Local IR input S1 Local serial port P1
Local IR output D1 TPS serial link P2
TPS IR input S2
TPS IR output D2




