Chapter 17 VLAN Stacking (Q-in-Q) Setup
85
17.4 VLAN Stacking Commands and Setup Instructions
Table 17-2 VLAN Stacking Unit Commands
Unit Commands
Parameters Description
add svlan
Activate SVLAN feature—
automatically creates VLAN1
delete svlan
deactivate SVLAN features
create
vid
14094
creates a SVLAN (SVid)
deactivate
vid
14094
deactivates a specific SVLAN
pvid
vid
14094
interface name
lan1/,wan1/
wan1 pvc1/….
set up the PVID for one bridge
interface (default is 1)
Port-type
Provider /
Customer
interface name
lan1/,wan1/
wan1 pvc1/….
set up the port type for one bridge
interface (default LAN is customer,
wan is provider.)
ingress-
filter
action
enable /disable
interface name
lan1/,wan1/
wan1 pvc1/….
enable/disable ingress filtering ability
for one bridge interface (default is
disabled)
add
vid
14094
interface name
lan/,wan1/
wan1pvc1/….
add a bridge interface to be one
member for a specific SVLAN
remove
vid
14094
interface name
lan/,wan1/
wan1 pvc1/….
remove a bridge interface from a
specific SVLAN
mgmt
vid
14094
set the VLAN to the bridge it belongs
to (default is 1)
tpid
Value
0-ffff
Set the svlan tag type, default is 8100.
pcp
Value
0-7
Set the svlan priority code point.
dei
Action
enable/disable
Set the svlan drop eligible indicator bit.
set svlan
regencrc
action
enabled/disabled
enabling will cause all wan interfaces
(virtual channels) to regenerate the
CRC value on the WAN links
Note: This will reduce the
performance for bridge forwarding.
table
start: initial entry in the SVLAN table
end: final entry in the SVLAN table
display the SVLAN table
port
Interface name
lan/,wan1/wan1 pvc1/….
display SVLAN information for all
bridge interfaces or one specific
interface
show svlan
state
display SVLAN information about the
VLAN state, Mgmt. VID, etc.
