Loop Telecom IP6610 User Manual

Chapter 2 Loop-IP6610 Installation
6
2.5.4 DTE Connections
The DTE Port is configured as a DCE device. There are six different DTE boards: V.35/M34, V.35/DB25,
EIA530/DB25,X.21/DB15, and RS232/DB25; and one DCE board: V.35 Female. Pin definitions are defined
in Table 2-5 to 10.
Table 2-5 V.35/M34 DTE Port Pin Definition
Pin Number Signal Source
A Cable Shield
B Signal Ground
C Request To Send DTE
D Clear To Send DCE
E Data Set Ready DCE
F Data Carrier Detect DCE
H Data Terminal Ready DTE
J Unassigned
K Unassigned
L Local Loopback DTE
M Unassigned
N Remote Loopback DTE
P Transmit Data DTE
R Receive Data DCE
S Transmit Data Return DTE
T Receive Data Return DCE
U External Clock DTE
V Receive Clock DCE
W External Clock Return DTE
X Receive Clock Return DCE
Y Transmit Clock DCE
Z Unassigned
AA Transmit Clock Return DCE
BB Unassigned
CC Unassigned
DD Unassigned
EE Unassigned
FF Unassigned
HH Unassigned
JJ Unassigned
KK Unassigned
LL Unassigned
MM Unassigned
NN Test Mode DCE
