Loop Telecom IP6610 User Manual

Chapter 1 Product Description
4
1.3 Specifications
E1 Line Interface
Line Rate 2.048 Mbps ± 50 ppm
Data Rate User configurable:
n x 64Kbps (n=1 to 31) – ITU G.704
2048Kbps (clear channel) – ITU G.703
Line Code AMI/ HDB3 (selectable)
Output signal ITU G.703
Input signal ITU G.703
Jitter ITU G.823
Electrical
75 coax/120 twisted pair
Connector BNC (75 ohm), RJ48C (120 ohm, twisted pair) (ordering option)
Compliance ITU G.703, ITU G.704 (E1 unframed, E1 framed)
DS1 Line Interface
Line Rate
1.544 Mbps  32 ppm
Data Rate n x 64Kbps (n=1-24)
Line Code AMI/B8ZS
Framing D4/ESF
Output Signal DSX-1 w/0, -7.5, -15 dB LBO
Input Signal DSX-1 0dB to –30dB w/ALBO
Jitter AT&T TR 62411
Connector DA15S or RJ48C
Pulse Template AT&T TR 62411
Surge Protection FCC Part 68 Sub Part D
DTE Interface- V.35
Connector DB25 Male
Data Rate Up to 8.192 Mbps
DTE Interface-RS449/V.36
Conversion Cable DB25 Male to DB37 Female conversion cable
Data Rate Up to 8.192 Mbps
DTE Interface- EIA530
Connector DB25 Male
Data Rate Up to 8.192 Mbps
DTE Interface-RS232
Connector DB25 Male
Data Rate Synchronous : Up to 128 Kbps
Asynchronous: 2.4K, 4.8K, 9.6K, 9.2K, 34.8K, 57.6K, 115.2Kbps
Function AT command
DTE Interface- X.21
Connector DB15 Male
Data Rate Up to 8.192 Mbps
DCE Interface-V.35
Connector DB25 Female
Data Rate 2.048 Mbps
Physical Interface
˙ WAN: E1/FE1, DS1/FDS1 (Integrated CSU/DSU)
 DTE (V.35/ V.36/ X.21/ RS232/ EIA530/ RS449)
 DCE (V.35)
˙ LAN: 10/100 Base-T Ethernet port
