Loop Telecom IP6610 User Manual

Chapter 3 Operation
15
Report Type Category Report
[Menu Command] ES UAS
BES
SES
CSS
BPV
1-Hour Terminal USER [Network]
Y Y Y Y Y --
Reports LINE [Network]
N/C N/C N/C N/C N/C --
24-Hour Terminal USER [Network]
Y Y Y Y Y Y
Reports LINE [Network]
N/C N/C N/C N/C N/C N/C
Y = Report available and can be cleared by admin terminal command “Y”.
X = Report available and can be cleared by admin terminal command “X”.
N/C = No clear. Report available, but counts cannot be cleared by the user.
-- = Report not available.
3.13 Unit Alarm Code Filters
A filtering system exists to bring hierarchical order to alarm types. These filters separate the alarm types
into various categories that are listed in Table 3-12, below.
Table 3- 14 Alarm Code Hierarchy
Alarm Code Hierarchy
Alarm Type Object ID Description
MCLK_LOSS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.0
Indicates Line Master clock los alarm
at local site
YEL_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.1
Indicates Line YEL alarm at local site
AIS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.2
Indicates Line AIS alarm at local site
LOS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.3
Indicates Line LOS alarm at local site
LOF_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.4
Indicates Line LOF alarm at local site
BPV_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.5
Indicates Line BPV alarm at local site
ES_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.6
Indicates Line ES alarm at local site
UAS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.7
Indicates Line UAS alarm at local site
CSS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.8
Indicates Line CSS alarm at local site
ETHER1_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.9
Indicates Ethernet 1 up or down
ETHER2_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.10
Indicates Ethernet 2 up or down
ETHER3_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.11
Indicates Ethernet 3 up or down
ETHER4_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.12
Indicates Ethernet 4 up or down
DCD_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.13
Indicates DTE DCD alarm at local site
CTS_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.14
Indicates DTE CTS alarm at local site
DSR_ALARM
1.3.6.1.4.1.823.6612.2.4.1.1.2.15
Indicates DTE DSR alarm at local site
3.14 Embedded SNMP Agent
The embedded SNMP agent for Loop-IP 6610 offers standard RFC 1213 MIB II and RFC 1406 DS1 MIB as
well as Loop Telecom's enterprise MIB. Network manager can use any SNMP compatible network
