Chapter 21 Appendix A: Operation Commands
112
Table 21-3 DS1 Command Lines
DS1 Command Lines
Command Parameters Description Br.
Rt.
Level
loopback
loopback-type
line, payload
activate a DS1 diagnostic loopback V
V Admin
remote_
loopback
remote-loopback-code-type
in-band, at&t-payload/ ansi-payload/ ansi-line
activate DS1 remote loopback V
V Admin
pattern type 3-in-24/1-in-8/2-in-8/1:1
activate test pattern V
V Admin
activate DS1
bert type full/wan1/idle
activate DS1 line BERT V
V Admin
add time
slot
wan_intf
wan1
start TS
1 ~ 24
[end TS]
1 ~ 24
add one or more DS1 time slots to wan1net address V
V Admin
delete time
slot
wan_intf
wan1
start TS
1 ~ 24
remove one or more DS1 time slots from wan1 V
V Admin
delete performance
delete DS1 performance data V
V OP
bert
release DS1 bert V
V Admin
loopback
release a DS1 loopback
remote_loopback Remote-loopback-code-type
in-band, at&t-payload, ansi-payload, ansi-line
release a DS1 remote loopback
V
V Admin
release
pattern
release DS1 pattern V
V Admin
frame framing mode
D4/ESF/ESF&DS1.403
set DS1 line framing V
V Admin
code coding mode AMI/B8ZS
set DS1 line coding mode V
V Admin
lbo setting 0dB/-7.5dB/-15dB
set DS1 line LBO V
V Admin
idle_code idle code
0x00 ~ 0xff
set DS1 unused channel idle code V
V Admin
yel setting on/off
enable/disable DS1 YEL V
V Admin
inband setting
on/off
enable/disable DS1 inband loopback code V
V Admin
address setting csu,te
set DS1 address V
V Admin
primary_cl
k
clock source line/internal
set DS1 primary clk source V
V Admin
secondary
_clk
clock source
line/internal
set DS1 secondary clk source V
V Admin
set DS1
timer timing
0~86400
set DS1 diagnostic function timer V
V Admin
diagnostic
show DS1 diagnostic status and BERT result V
V OP
show DS1
line availability
show DS1 line availability V
V OP
