Loop Telecom IP6610 User Manual

Chapter 7 Frame Relay Setup
35
7.2 Frame Relay Setup Commands
To set up the Frame Relay application you will use the commands in Table 7-1, below. Step by step
instructions follow the table.
Table 7-1 Frame Relay Setup Commands
Frame Relay Setup Commands
Command
Parameters Description Brg
Rt
Privilege
protocol protocol-
type
hdlc/
ppp/
chdlc/
frame_relay
[protocol]
ansi/q93
3
[n391
value]
1-255
[n392
value]
1-10
[n393
value]
1-10
[t391
value]5-
30
set WAN1 layer 2
protocol
V V
Admin
pvc
dlci pvc#1~10 DLCI
0/16~991
[CIR]
[Bc] [Be] [burst]
Create/set/delete
WAN1 PVC
parameters.
When DLCI is 0,
the PVC will be
deleted.
V V
Admin
pvc
ip pvc#1~10 ip_addr
xxx.xxx.xxx.xxx
net_mask
xxx.xxx.xxx.xxx
Set a PVC’s IP
address
--
V
Admin
set wan1
pvc
routing
pvc# routing_protocol rip1/rip2/static Set a PVC’s layer3
routing protocol
--
V
Admin
