Chapter 2 Loop-IP6610 Installation

Table 2-9 RS232/DB25 DTE Port Pin Definition

Pin Number Signal Source

1 Cable Shield

2 Transmit Data DTE

3 Receive Data DCE

4 Request To Send DTE

5 Clear To Send DCE

6 Data Set Ready DCE

7 Signal Ground

8 Data Carrier Detect DCE

9 Unassigned

10 Unassigned

11 Unassigned

12 Unassigned

13 Unassigned

14 Unassigned

15 Transmit Clock DCE

16 Unassigned

17 Receive Clock DCE

18 Local Loopback DTE

19 Unassigned

20 Data Terminal Ready DTE

21 Remote Loopback DTE

22 Unassigned

23 Unassigned

24 External Clock DTE

25 Test Mode DCE
