LSIS G100 User Manual

Code and
Features
Description
5
Output
Power
Monitors output wattage. 200% of rated output is
the maximum display voltage (10 V).
6
Idse
Outputs the maximum voltage at 200% of no load
current. Outputs 0 V during V/F operation or slip
compensation operation since it is an output of the
magnitude of the current on the magnetic flux
portion.
7
Iqse
Outputs the maximum voltage at 250% of rated
torque current.
8
Target
Freq
Outputs set frequency as a standard. Outputs 10 V
at the maximum frequency (dr.20).
9
Ramp
Freq
Outputs frequency calculated with Acc/Dec function
as a standard. May vary with actual output
frequency. Outputs 10 V.
12
PID Ref
Value
Outputs command value of a PID controller as a
standard. Outputs approximately 6.6 V at 100%.
13
PID Fdk
Value
Outputs feedback volume of a PID controller as a
standard. Outputs approximately 6.6 V at 100%.
14
PID
Output
Outputs output value of a PID controller as a
standard. Outputs approximately 10 V at 100%.
15
Constant
Outputs OU.05 (AO1 Const%) value as a standard.
OU.02 AO1 Gain,
OU.03 AO1 Bias
Adjusts output value and offset. If frequency is selected as an output
item, it will operate as shown below.
 


   
The graph below illustrates the analog voltage output (AO1) changes
depend on OU.02 (AO1 Gain) and OU.3 (AO1 Bias) values. Y-axis is
analog output voltage (0–10 V), and X-axis is% value of the output
item.
Example, if the maximum frequency set at dr.20 (Max Freq) is 60 Hz
and the present output frequency is 30 Hz, then the x-axis value on
the next graph is 50%.
