LSIS G100 User Manual

Code and
Features
Description
19
Speed Search
(Speed
Search)
Outputs a signal during inverter speed search
operation.
For details, refer to 5.13 Speed Search
Operation on page 145.
21
Regeneration
(Regeneration)
Outputs signal if the motor is operating under
regeneration mode.
Braking resistance is activated when the
inverter DC voltage is higher than the voltage
set in Ad-79 and this feature operates only
when the inverter is operating.
22
Ready
(Ready)
Outputs signal when the inverter is in stand by
operation and ready to receive an external
operation command.
23
FDT-5 (Zspd)
Outputs signal that is lower than the frequency
set in iOU-57 and OU-58.
28
Timer Out
This is a feature to activate the contact output
after a certain period of time using the multi-
function terminal block. For details, refer to
5.24 on page 160.
29
Trip
Outputs a signal after a fault trip.
Refer to 5.26 Off
Control on page 162 for more details.
31
DB Warn%ED
Refer to 6.2.5 Dynamic Braking (DB)
Resistor Configuration on page 191.
34
On/Off Control
Outputs a signal using an analog input value
as a standard.
Refer to 5.26 Off
Control on page 162 for more details.
35
BR Control
Outputs a brake release signal.
Refer to 5.25 Brake Control on page 161 for
more details.
40
KEB Operating
This outputs when the energy buffering
operation is started because of low voltage of
the inverter's DC power section due to a power
failure on the input power. (This outputs in the
energy buffering state before the input power
restoration regardless of KEB-1 and KEB-2
mode settings.)
42
Minor Fault
Outputs signal when inverter is under warning
status.
5.29.2 Trip Output to Multi-Function Relay
