7.2.2 Setting Communication Parameters
Before proceeding with setting communication configurations, make sure that the
communication lines are connected properly. Turn on the inverter and set the
communication parameters.
Grou
p
Code
Name
Setting
Setting
Range
Unit
CM
01
Built-in communication
inverter ID
1
1–250
-
02
Built-in communication
protocol
0
ModBus
RTU
0, 2
-
03
Built-in communication
speed
3
9600 bps
0–7
-
04
Built-in communication
frame setting
0
D8/PN/S
1
0–3
-
05
Transmission delay after
reception
5
0–1000
ms
Communication Parameters Setting Details
Code and
Features
Description
CM.01 Int485 St
ID
Set the inverter station ID between 1 and 250.
CM.02 Int485
Proto
Select one of the two built-in protocols: Modbus-RTU or LS INV 485.
Configuration
Function
0
Modbus-RTU
Modbus-RTU compatible protocol
2
LS INV 485
Dedicated protocol for the LS inverter
