LSIS G100 User Manual

Code
Comm.
Address
Name
Setting Range
Initial
Value
Property
*
V/
F
S
L
Ref.
pattern
1
Square
Linear
2
User V/F
3
Square 2
bA-08
0h1208
Acc/Dec
reference
frequency
0
Max Freq
0: Max
Freq
X
O
O
p.78
1
Delta Freq
bA-09
0h1209
Time
scale
setting
0
0.01 sec
1: 0.1 sec
X
O
O
p.78
1
0.1 sec
2
1 sec
bA-10
0h120A
input
power
frequency
0
60 Hz
0: 60 Hz
X
O
O
p.156
1
50 Hz
bA-11
0h120B
Number of
motor poles
2–48
Dependen
t on motor
setting
X
O
O
p.122
bA-12
0h120C
Rated slip
speed
0–3000 (Rpm)
X
O
O
p.122
bA-13
0h120D
Motor
rated
current
1.0–1000.0 (A)
X
O
O
p.122
bA-14
0h120E
Motor
noload
current
0.0–1000.0 (A)
X
O
O
p.122
bA-15
0h120F
Motor
rated
voltage
0, 100–480 (V)
0
X
O
O
p.91
bA-16
0h1210
Motor
efficiency
64–100 (%)
Dependen
t on motor
setting
X
O
O
p.122
bA-17
0h1211
Load
inertia
rate
0–8
0
X
O
O
p.122
bA-18
0h1212
Trim
power
display
70–130 (%)
100%
O
O
O
-
bA-19
0h1213
Input
power
voltage
170–480 V
220/380 V
O
O
O
p.156
bA-20
-
Auto
tuning
0
None
0: None
X
X
O
p.131
1
All (Rotation type)
2
All (Static type)
3
Rs+Lsigma
(Rotation type)
6
Tr (Static type)
bA-21
-
Stator
Dependent on motor
Dependen
X
X
O
p.131
