LSIS G100 User Manual

Code
Comm.
Addres
s
Name
Setting Range
Initial
Value
Prop
erty*
V/
F
S
L
Ref.
In-09
0h1509
V1 output at
Minimum
voltage (%)
0.00–100.00 (%)
0.00
O
O
O
p.61
In-10
0h150A
V1 Maximum
input voltage
0.00–12.00 (V)
10.00
O
O
O
p.61
In-11
0h150B
V1 output at
Maximum
voltage (%)
0.00–100.00 (%)
100.00
O
O
O
p.61
In-12
29
0h150C
V1 Minimum
input voltage
-10.00–0.00 (V)
0.00
O
O
O
p.65
In-13
29
0h150D
V1 output at
Minimum
voltage (%)
-100.00–0.00 (%)
0.00
O
O
O
p.65
In-14
29
0h150E
V1 Maximum
input voltage
-12.00–0.00 (V)
-10.00
O
O
O
p.65
In-15
29
0h150F
V1 output at
Maximum
voltage (%)
-100.00–0.00 (%)
-100.00
O
O
O
p.65
In-16
0h1510
Changing
rotation
direction of
V1
0
No
0: No
O
O
O
p.61
1
Yes
In-17
0h1511
V1
quantization
level
0.00
30
, 0.04–10.00
(%)
0.04
X
O
O
p.61
In-35
0h1523
V0 input
voltage
display
0.00–5.00 (V)
0.00
-
O
O
p.67
In-37
0h1525
Time constant
of V0 input
filter
0–10000 (ms)
100
O
O
O
p.67
In-38
0h1526
V0 Minimum
input voltage
0.00–5.00 (V)
0.00
O
X
O
p.67
In-39
0h1527
V0 output at
Minimum
voltage (%)
0.00–100.00 (%)
0.00
O
O
O
p.67
29
30
