LSIS G100 User Manual

Code
Comm.
Address
Name
Setting
Range
Initial Value
Prop
erty*
V/
F
S
L
Ref.
M2-08
0h1C08
Control mode
0
V/F
0: V/F
X
O
O
p.152
2
Slip
Compen
4
IM
Sensorless
M2-10
0h1C0A
Number of
motor poles
2–48
Dependent
on motor
setting
X
O
O
p.152
M2-11
0h1C0B
Rated slip
speed
0–3000
(Rpm)
X
O
O
p.152
M2-12
0h1C0C
Motor rated
current
1.0–1000.0
(A)
X
O
O
p.152
M2-13
0h1C0D
Motor noload
current
0.5–1000.0
(A)
X
O
O
p.152
M2-14
0h1C0E
Motor rated
voltage
170–480 (V)
X
O
O
p.152
M2-15
0h1C0F
Motor efficiency
64–100 (%)
X
O
O
p.152
M2-16
0h1C10
Load inertia rate
0–8
X
O
O
p.152
M2-17
-
Stator
resistance
Dependent
on motor
setting
X
O
O
p.152
M2-18
-
Leakage
inductance
X
O
O
p.152
M2-19
-
Stator
inductance
X
O
O
p.152
M2-20
44
-
Rotor time
constant
25–5000 (ms)
X
O
O
p.152
M2-25
0h1C19
V/F pattern
0
Linear
0: Linear
X
O
O
p.152
1
Square
2
User V/F
M2-26
0h1C1 A
Forward Torque
boost
0.0–15.0 (%)
2.0
X
O
O
p.152
M2-27
0h1C1B
Reverse torque
boost
0.0–15.0 (%)
X
O
O
p.152
M2-28
0h1C1C
Stall prevention
level
30–150 (%)
150
X
O
O
p.152
M2-29
0h1C1D
Electronic
thermal 1
minute rating
100–200 (%)
150
X
O
O
p.152
M2-30
0h1C1E
Electronic
thermal
continuous
rating
50–Electronic
thermal 1
minute rating
100
X
O
O
p.152
44
