Items
Description
Output
Multi-
function
relay
terminal
Fault output and inverter
operation status output
Less than (N.O., N.C.) AC
250 V, 1 A, 
Less than DC 30 V, 1 A
Analog
output
0–12 Vdc: Select frequency, output current, output
voltage, DC terminal voltage and others
Protection
function
Trip
• Over current trip
• External signal trip
• ARM short current fault
trip
• Over heat trip
• In phase open trip
• Ground trip
• Motor over heat trip
• I/O board link trip
• No motor trip
• Parameter writing trip
• Emergency stop trip
• Command loss trip
• External memory error
• CPU watchdog trip
• Motor light load trip
• Over voltage trip
• Temperature sensor trip
• Inverter over heat
• Option trip
• Out phase open trip
• Inverter overload trip
• Fan trip
• Pre-PID operation failure
• External brake trip
• Low voltage trip during
operation
• Low voltage trip
• Analog input error
• Motor overload trip
• Over torque trip
• Under torque trip
Alarm
Command loss trip warning, overload warning, light load
warning, inverter overload warning, fan operation
warning, braking resistance braking rate warning, rotor
time constant tuning error, inverter pre-overheat
warning, over torque warning, under torque warning
Instantaneous
blackout
Heavy load less than 15 ms (normal load less than 8
ms):
(must be within the rated input voltage and rated output
range)
Heavy load more than 15 ms (normal load more than 8
ms): auto restart operation
Structure/
working
environment
Cooling type
Forced fan cooling structure
Protection
structure
IP 20, UL Open Type
(UL Enclosed Type 1 is satisfied by conduit installation
option.)
Ambient
temperature
Heavy load: -10–50℃, Normal load: -10–40℃
No ice or frost should be present.
Working under normal load at 50℃ (122°F), it is
recommended that less than 80% load is applied.
Ambient humidity
Relative humidity less than 95% RH (to avoid
condensation forming)
