11.6 Terminal Screw Specification
Input/output Terminal Screw Specification
Capacity (kW)
Terminal Screw Size
Rated Screw Torque
(Kgfcm/Nm)
3-phase
200 V
0.4
R/S/T, U/V/W: M3
R/S/T, U/V/W: 5.1 / 0.5
0.75
1.5
R/S/T, U/V/W: M4
R/S/T, U/V/W: 12.1 / 1.2
2.2
4
R/S/T, U/V/W: M4
R/S/T, U/V/W: 18.4 / 1.8
5.5
R/S/T, U/V/W : M4
R/S/T : 14.0 / 1.4
U/V/W : 15.0 / 1.5
7.5
3-phase
400 V
0.4
R/S/T, U/V/W: M3.5
R/S/T, U/V/W: 10.3 / 1.0
0.75
1.5
2.2
4
R/S/T, U/V/W: M4
R/S/T, U/V/W: 18.4 / 1.8
5.5
R/S/T, U/V/W : M4
R/S/T : 14.0 / 1.4
U/V/W : 18.4 / 1.8
7.5
Control Circuit Terminal Screw Specification
Terminals
Terminal Screw Size
Screw Torque (Kgfcm/Nm)
P1-
P5/CM/VR/V1/I2/AO/24/S+/S-
M2
2.2–2.5/0.22–0.25
A1/B1/C1, A2/C2
M2.6
4.0/0.4
