Alarms for UMS – Class and MAN Diesel & Turbo requirements
ABS
BV
CCS
DNV
GL
KR
LR
NK
RINA
RS
IACS
MAN Diesel
Sensor and
function Point of location
Exhaust gas
1 1 1 1 1 1 (1) 1 1 1 1 1 TC 8701 AH Exhaust gas before turbocharger/turbocharger
1 1 1 1 1 1 1 1 1 1 TC 8702 AH Exhaust gas after exhaust valve, cylinder/cylinder
1 1 1 1 1 1 1 1 1 1 1 TC 8707 AH Exhaust gas outlet turbocharger/turbocharger (Yard’s
supply)
Miscellaneous
1 WT 8812 AH Axial vibration monitor 2)
1 1 1 1 1 1 1 1 1 1 1 XS 8813 AH Oil mist in crankcase/cylinder; sensor common to
XS 8813/14
1 1 XS 8814 AL Oil mist detector failure
1 XC 8816 I Shaftline earthing device
1 TE 8820 AH Cylinder liner monitoring/cylinder 3)
Engine Control System
1 1 1 1 1 1 1 1 1 1 1 1 XC 2201 A Power failure
1 1 1 1 1 1 1 1 1 1 XC 2202 A ME common failure
1 XC 2202-A A ME common failure (ME-GI only)
1 XC 2213 A Double-pipe HC alarm (ME-GI only)
Power Supply Units to Alarm System
1 XC 2901 A Low voltage ME power supply A
1 XC 2902 A Low voltage ME power supply B
1 XC 2903 A Earth failure ME power supply
1 Indicates that the sensor is required.
The sensors in the MAN Diesel and relevant Class columns are included in the basic Extent of Delivery, EoD: 4 75 127.
The sensor identification codes and functions are listed in Table 18.07.01.
The tables are liable to change without notice, and are subject to latest Class requirements.
(1) May be combined with TC 8702 AH where turbocharger is mounted directly on the exhaust manifold.
2) Required for: K-ME-C6/7 and K98ME6/7 engines with 11 and 14 cylinders incl. ME-GI variants.
All ME-C9/10 and ME-B9 engines incl. ME-GI variants.
All ME-C7/8 and ME-B8 engines with 5 and 6 cylinders incl. ME-GI variants.
3) Required for: K98ME/ME-C, S90ME-C, K90ME-C and K80ME-C9 engines incl. ME-GI variants.
Alarm for overheating of main, crank and crosshead bearings, option: 4 75 134.
Table 18.04.02c: Alarm functions for UMS
