Slow down for UMS – Class and MAN Diesel & Turbo requirements
Table 18.04.03: Slow down functions for UMS
ABS
BV
CCS
DNV
GL
KR
LR
NK
RINA
RS
IACS
MAN Diesel
Sensor and
function Point of location
1 1 1 1 1 1 1 1 1 1 1 1 TE 8106 YH Thrust bearing segment
1 1 1 1* 1 1 1 1 1 1 1 1 PT 8108 YL Lubricating oil inlet to main engine
1 1 TE 8112 YH Lubricating oil inlet to main engine
1 1 1 1 1 1 1 1 1 1 1 TE 8113 YH Piston cooling oil outlet/cylinder
1 1 1 1 1 1 1 1 1 1 1 FS 8114 YL Piston cooling oil outlet/cylinder
1 TE 8123 YH Main bearing oil outlet temperature/main bearing
(S40/35ME-B9 only)
1 XC 8126 YH Bearing wear (All except S40/35ME-B9)
1 1 1 1 1 1 1 1 1 1 1 PT 8401 YL Jacket cooling water inlet
1 PDT 8403 YL Jacket cooling water across engine (Not for LDCL)
1 PDT 8404
YL
Jacket cooling water across cylinder liners (Only for
LDCL)
1 PDT 8405
YL
Jacket cooling water across cylinder covers and ex-
haust valves (Only for LDCL)
1 1 1 1 1 1 1 1 1 1 1 1 TE 8408 YH Jacket cooling water outlet, cylinder/cylinder
1 1 1 TE 8609 YH Scavenge air receiver
1 1 1 1 1 1 1 1 1 1 1 1 TE 8610 YH Scavenge air box fire-alarm, cylinder/cylinder
1 1 1 TC 8701 YH Exhaust gas before turbocharger/turbocharger
1 1 1 1 1 1 1 1 1 1 1 TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder
1 1 TC 8702 YH Exhaust gas after exhaust valve, cylinder/cylinder,
deviation from average
1 WT 8812 YH Axial vibration monitor 2)
1 1 1* 1 1 1 1 1 1 1 XS 8813 YH Oil mist in crankcase/cylinder
1 XS/XT
8817 Y
Turbocharger overspeed (Only in case of VT TC, Waste
Heat Recovery, Exhaust Gas Bypass, TC Cut-out)
1 1 TE 1310 YH Lubrication oil inlet (Only for ME/-GI with separate oil
system to HPS installed)
1 Indicates that the sensor is required.
The sensors in the MAN Diesel and relevant Class columns are included in the basic Extent of Delivery, EoD: 4 75 127.
The sensor identification codes and functions are listed in Table 18.07.01.
The tables are liable to change without notice, and are subject to latest Class requirements.
2) Required for: K-ME-C6/7 and K98ME6/7 engines with 11 and 14 cylinders incl. ME-GI variants.
All ME-C9/10 and ME-B9 engines incl. ME-GI variants.
All ME-C7/8 and ME-B8 engines with 5 and 6 cylinders incl. ME-GI variants.
Select one of the alternatives * Or shut down
Or alarm for low flow * Or shut down
Or alarm for overheating of main, crank and crosshead bearings, option: 4 75 134.
See also Table 18.04.04: Shut down functions for AMS and UMS
